Simplex Fiber Optic Cable

The simplex fiber optic cable uses a single Φ900μm or Φ600μm tight-buffered optical fiber as the optical transmission medium, covered with a layer of aramid as a reinforcement, and extruded with a layer of polyvinyl chloride (PVC) or low-smoke zero-halogen material (LSZH, low-smoke, halogen-free, flame-retardant) sheath.

Send Inquiry

Product Description

Orientalfiber, a professional Simplex Fiber Optic Cable manufacturer and supplier in China, offers high-quality cables suitable for various indoor communication applications. Our simplex fiber optic cables feature tight buffer fiber for easy stripping and excellent flame-retardant performance, with aramid yarn providing superior tensile strength. The durable outer jacket resists corrosion, water, ultraviolet radiation, and fire, while remaining environmentally safe.

Characteristics

Tight buffer fibre easy of stripping

Tight buffer fibre have excellent flame-retardant performance

Aramid yarn as strength member make simplex fiber optic cable have excellent tensile strength

The outer jacket material has many advantages such as anti-corrosion, anti-water, anti-ultraviolet radiation, flame-retardant and harmless to environment etc.

Applications

Making patch cords or pigtails

Indoor distribution

Interconnect between instruments, communication equipments

Standards

Meet the standards of YD/T 1258.2, ICEA-596, GR-409, IEC 60794-2-10/11, etc. In addition to ordinary PVC products, there are also products that have passed ULOFNR and OFNP certifications. LSZH products use different materials to meet IEC60332-1 or IEC60332-3C or OFNR certifications.

Structure Drawing

1.Tight Buffer Fibre

2.Aramid Yarn

3.Jacket

Simplex Fiber Optic Cable

Technical Parameters

Cable Model	Cable Diameter (Ref) (mm)	Cable Weight (Ref) (kg/km)		TBF Diameter (µm)	Tensile Strenght Long/Short Term (N)	Crush Resistance Long/Short Term (N/100mm)	Bending Radius Dynamic/Static (mm)
Cable Model	Cable Diameter (Ref) (mm)	PVC Jacket	LSZH Jacket	TBF Diameter (µm)	Tensile Strenght Long/Short Term (N)	Crush Resistance Long/Short Term (N/100mm)	Bending Radius Dynamic/Static (mm)
1.6	1.6±0.2	2.4	2.6	600±50	40/80	100/500	60/30
1.9	1.9±0.2	3.5	4.5	900±50	60/100	100/500	60/30
2.8	2.8±0.2	6.0	7.5	900±50	60/100	100/500	60/30

Optical Characteristics

Fiber Type	Attenuation				OFL	Effective Mode Bandwidth	10 Gbit/s Ethernet Link Length	Minimum Bend Radius
Condition	1310/1550nm		850/1300nm		850/1300nm	850nm	850nm	/
Condition	Typical Value	Maximum Value	Typical Value	Maximum Value	850/1300nm	850nm	850nm	/
Unit	dB/km	dB/km	dB/km	dB/km	MHZ.km	MHZ.km	m	mm
G652D	0.36/0.22	0.5/0.4	---	---	---	---	---	16
G657A1	0.36/0.22	0.5/0.4	---	---	---	---	---	10
G657A2	0.36/0.22	0.5/0.4	---	---	---	---	---	7.5
50/125	---	---	3.0/1.0	3.5/1.5	≥500/500	---	---	30
62.5/125	---	---	3.0/1.0	3.5/1.5	≥200/500	---	---	30
OM3	---	---	3.0/1.0	3.5/1.5	≥1500/500	≥2000	≤300	30
OM4	---	---	3.0/1.0	3.5/1.5	≥3500/500	≥4700	≤550	30
