Special low-bend-sensitivity fibre provides high bandwidth and excellent communication transmission property
Two parallel FRP or steel wires make the cable have good compression resistance and protect the optical fiber
The bow-type fiber optic drop cable has a simple structure and strong practicality
Novel flute design, easily strip and splice, simplify the installation and maintenance
Low smoke, zero halogen and flame retardant sheath
1.LSZH Jacket
2.FRP Strength Member
3.Optical Fibre Unit
|
Cable Model |
Fiber Count |
Cable Size (mm) |
Cable Weight (Ref) (kg/km) |
Tensile Strength Long/Short Term (N) |
Crush Resistance Long/Short Term (N/100mm) |
Bending Radius Dynamic/Static (mm) |
|
GJXFH-1Xn |
1 |
(2.0±0.1)*(3.0±0.1) |
8 |
40/80 |
500/1000 |
15/30 |
|
GJXFH-2Xn |
2 |
(2.0±0.1)*(3.0±0.1) |
8.5 |
40/80 |
500/1000 |
15/30 |
|
GJXFJH-1Xn |
1 |
(2.0±0.1)*(3.8±0.1) |
9 |
40/80 |
500/1000 |
15/30 |
|
GJXFDH-4Xn |
4(Ribbon) |
(2.0±0.2)*(4.0±0.2) |
10 |
40/80 |
500/1000 |
15/30 |
Storage/Operating Temperature:-20℃~+60℃
|
Fiber Type |
Attenuation |
OFL |
Effective Mode Bandwidth |
10 Gbit/s Ethernet Link Length |
Minimum Bend Radius |
|||
|
Condition |
1310/1550nm |
850/1300nm |
850/1300nm |
850nm |
850nm |
/ |
||
|
Typical Value |
Maximum Value |
Typical Value |
Maximum Value |
|||||
|
Unit |
dB/km |
dB/km |
dB/km |
dB/km |
MHZ.km |
MHZ.km |
m |
mm |
|
G657A1 |
0.36/0.22 |
0.5/0.4 |
--- |
--- |
--- |
--- |
--- |
10 |
|
G657A2 |
0.36/0.22 |
0.5/0.4 |
--- |
--- |
--- |
--- |
--- |
7.5 |
|
OM3 |
--- |
--- |
3.0/1.0 |
3.5/1.5 |
≥1500/500 |
≥2000 |
≤300 |
30 |
|
OM4 |
--- |
--- |
3.0/1.0 |
3.5/1.5 |
≥3500/500 |
≥4700 |
≤550 |
30 |
