Color-inked Coated Fiber

Our high quality Color-inked Coated Fiber are all made in China. Orientalfiber is a professional the Color-inked Coated Fiber manufacturer and supplier in China. You can buy them from our factory. For more information, contact us now.

Structure parameter

Item		Specification
Fiber Count		1 core
Coated fiber	Dimension	250 µm
	Color	Natural
Tight cladding	Diameter	0.26±0.005 mm 0.27±0.005 mm 0.28±0.005 mm 0.30±0.005 mm
	Material	Resin
	Color	Natural, Black or Green

Mechanical and Environmental Characteristics

Item		Unit	Specification
Tension		N	45
Crush		N/100mm	90
Min. bend radius	Static	mm	10D
	Dynamic	mm	15D
Operating temperature		℃	-40～+75
