FTTH indoor vertical wiring
Building trunk wiring optical cable
Good structural design, easy to branch and extract
Small size, light weight, easy to install
Low smoke halogen-free sheath ensures good flame retardancy
Precise process control ensures mechanical and temperature performance
Especially suitable for cutting, extraction, skylight opening
| Cable Type | Cable Diameter | Cable Weight | Tensile Strength Long/Short term | Crush Resistance Long/Short | Bending Radius Dynamic/Static | Storage temperature |
| (mm) | (kg/km) | (N) | (N) | (mm) | (℃) | |
| GJPFWQH-24 (4cx6s) | 6.5±0.2 | 40 | 200/500 | 200/1000 | 20D/10D | -20°C ~ +60 |
| GJPFWQH-48 (4cx12s) | 8.5±0.2 | 60 | 200/500 | 200/1000 | 20D/10D | -20°C ~ +60 |
| GJPFWQH-96 (8cx12s) | 10.5±0.2 | 90 | 200/500 | 200/1000 | 20D/10D | -20°C ~ +60 |
| GJPFWQH-144 | 10.5±0.2 | 90 | 300/500 | 200/1000 | 20D/10D | -20°C ~ +60 |
| GJPFWQH-144 | 13.5±0.2 | 145 | 300/500 | 200/1000 | 20D/10D | -20°C ~ +60 |
Note: Transport/storage temperature: -20°C ~ +60°C
Standard length: 2000m; other lengths are also available.
Fiber type: G652D, G657A1, G657A2, 50/125, 62.5/125, OM3, OM4, OM5
