All types of fibre cables with different structures
High-performance optical networks operating in the O-E-S-C-L band
High speed optical routes for Fibre-to-the-Home networks
Optical cables with high requirements about bending performance requirements
Small-sized fibre cable and optical component
ITU-T
IEC 60793-2-50 type B1.3/B6.a1/B6.a2/B6.b2 Optical Fibre Specification.
High resistance to bending losses in the bend radius range of 7.5 to 15 mm
Fully compatible with all G.652 optical fibers
Low attenuation meets the operation demand in O-E-S-C-L band
Low PMD meets high bit-rate and long-distance transmission requirements
Low bending loss
Accurate geometrical parameters
High nd-value
|
Characteristics |
Conditions |
Specified Values |
Units |
|
|
Optical Characteristics |
||||
|
Attenuation |
1310nm |
≤0.35 |
[dB/km] |
|
|
1383nm(after H2-aging) |
≤0.35 |
[dB/km] |
||
|
1460nm |
≤0.25 |
[dB/km] |
||
|
1490nm |
≤0.23 |
[dB/km] |
||
|
1550nm |
≤0.21 |
[dB/km] |
||
|
1625nm |
≤0.23 |
[dB/km] |
||
|
Attenuation vs. Wavelength Max. α difference |
1285-1330nm, in reference to 1310nm |
≤0.03 |
[dB/km] |
|
|
1525-1575nm, in reference to 1550nm |
≤0.02 |
[dB/km] |
||
|
Zero Dispersion Wavelength(λ0) |
-- |
1300-1324 |
[nm] |
|
|
Zero Dispersion Slope(S0) |
-- |
≤0.092 |
[ps/(nm2·km)] |
|
|
PMD |
Maximum Individual Fibre |
-- |
≤0.1 |
[ps/√km] |
|
Link Design Value(M=20，Q=0.01%) |
-- |
≤0.06 |
[ps/√km] |
|
|
Typical Value |
-- |
0.04 |
[ps/√km] |
|
|
Cable Cutoff Wavelength (λCC) |
-- |
≤1260 |
[nm] |
|
|
Mode Field Diameter(MFD) |
1310nm |
8.4-9.2 |
[μm] |
|
|
1550nm |
9.3-10.3 |
[μm] |
||
|
Effective Group Index of Refraction(Neff) |
1310nm |
1.466 |
-- |
|
|
1550nm |
1.467 |
-- |
||
|
Point Discontinuities |
1310nm |
≤0.05 |
[dB] |
|
|
1550nm |
≤0.05 |
[dB] |
||
|
Geometrical Characteristics |
||||
|
Cladding Diameter |
-- |
125.0±0.7 |
[μm] |
|
|
Cladding Non-Circularity |
-- |
≤0.7 |
[%] |
|
|
Coating Diameter |
-- |
235-245 |
[μm] |
|
|
Coating-Cladding Concentricity Error |
-- |
≤12.0 |
[μm] |
|
|
Coating Non-Circularity |
-- |
≤6.0 |
[%] |
|
|
Core-Cladding Concentricity Error |
-- |
≤0.5 |
[μm] |
|
|
Curl(radius) |
-- |
≥4 |
[m] |
|
|
Delivery Length |
-- |
Up to 50.4 |
[km/reel] |
|
|
Environmental Characteristics |
1310nm, 1550nm & 1625nm |
|||
|
Temperature Dependence Induced Attenuation |
-60℃ to +85℃ |
≤0.05 |
[dB/km] |
|
|
Temperature-Humidity Cycling Induced Attenuation |
-10°C to +85°C, 98% RH |
≤0.05 |
[dB/km] |
|
|
Watersoak Dependence Induced Attenuation |
23°C, for 30 days |
≤0.05 |
[dB/km] |
|
|
Damp Heat Dependence Induced Attenuation |
85°C and 85% RH, for 30 days |
≤0.05 |
[dB/km] |
|
|
Dry Heat Aging |
85℃, for 30 days |
≤0.05 |
[dB/km] |
|
|
Mechanical Specification |
||||
|
Proof Test |
-- |
≥9.0 |
[N] |
|
|
-- |
≥1.0 |
[%] |
||
|
-- |
≥100 |
[kpsi] |
||
|
Macro-bend Induced Attenuation |
10 Turns Around a Mandrel of 15 mm Radius |
1550nm |
≤0.03 |
[dB] |
|
10 Turns Around a Mandrel of 15 mm Radius |
1625nm |
≤0.1 |
[dB] |
|
|
1 Turn Around a Mandrel of 10 mm Radius |
1550nm |
≤0.1 |
[dB] |
|
|
1 Turn Around a Mandrel of 10 mm Radius |
1625nm |
≤0.2 |
[dB] |
|
|
1 Turn Around a Mandrel of 7.5 mm Radius |
1550nm |
≤0.5 |
[dB] |
|
|
1 Turn Around a Mandrel of 7.5 mm Radius |
1625nm |
≤1.0 |
[dB] |
|
|
Coating Strip Force |
typical average force |
1.5 |
[N] |
|
|
peak force |
1.3-8.9 |
[N] |
||
|
Dynamic Fatigue Parameter(nd) |
-- |
≥20 |
-- |
|
