China GDTA53 Single-mode Optical Fiber Manufacturer, Supplier, Factory

The structure of stranded loose tube armored fiber optic cable is to put 250μm optical fiber into a loose tube made of high modulus material, and the loose tube is filled with waterproof compound. The center of the cable core is a metal reinforcement core. For optical cables with certain cores, a layer of polyethylene (PE) needs to be extruded outside the metal reinforcement core. The loose tube (and filling rope) are twisted around the central reinforcement core to form a compact and round cable core, and the gaps in the cable core are filled with water-blocking fillers. A layer of polyethylene inner sheath is extruded outside the cable core, and a double-sided plastic-coated steel tape (PSP) is longitudinally wrapped and then extruded into a polyethylene sheath to form a cable.

The simplex fiber optic cable uses a single Φ900μm or Φ600μm tight-buffered optical fiber as the optical transmission medium, covered with a layer of aramid as a reinforcement, and extruded with a layer of polyvinyl chloride (PVC) or low-smoke zero-halogen material (LSZH, low-smoke, halogen-free, flame-retardant) sheath.
