Application: FTTx, Data Room Transformatio
● Easy operating, The connector can be directly used in ONU, also with fasten strength more than 5 kg, it is widely used in FTTH project of network revolution. It also reduce the use of sockets and adapters, save cost of project.
● With 86 standard socket and adapter, the connector makes connection between drop cable and patch cord. The 86 standard socket provides complete protection with its unique design.
● Applicable to connection with field mountable indoor cable, pigtail, patch cord and transformation of patch cord in data room and directly used in specific ONU.
| Item | Parameter |
| Cable Scope | 3.0 x 2.0 mm drop cable (2.0&3.0 optical cable) |
| Size: | 55*8.9*8.3 mm |
| Fiber Diameter | 125μm ( G 652 & G 657 ) |
| Coating Diameter | 250μm |
| Mode | SM |
| Operation Time | about 15s（exclude fiber presetting) |
| Insertion Loss | ≤ 0.5dB Max/Typically ≤0.3dB（1310nm & 1550nm) |
| Return Loss | ≥50dB for UPC, ≥55dB forAPC |
| Success Rate | >98% |
| Reusable Times | >10 times |
| Tighten Strength of Naked Fiber | >5 N |
| Tensile Strength | >40 N |
| Temperature | -40 ~ +85 C |
| On-line Tensile Strength Test (20 N) | IL range≤0.3dB RL range≤5dB |
| Mechanical Durability（500 times) | IL range≤0.3dB RL range≤5dB |
| Drop Test（4m concrete floor, once each direction, three times total) | IL range≤0.3dB RL range≤5dB |
