● FTTX/FTTH Systems
● Ethernet Applications
● CATV Links
● Optical Signal Distribution
● Passive Optical Networks (PON)
● Backbone, Horizontal and riser applications
● Preterminated Drop Terminal Boxes
● Outdoor Areas; Harsh Environment
● Low insertion loss, high return loss.
● Good in repeatability and exchangeability.
● 100% Insertion, Return Loss, End Face and.
● Interference inspection.
● Excellent mechanical endurance.
● Complying with Telcordia GR-326-Core.
● Ensures high performance and reliability in the management of optical cabling.
● Fast and easy installation and reconfiguration.
● Simple handling, no need for special tool.
● IP68 Waterproof.
| Constructions | Unit | Descriptions |
| Fiber Count | Simplex | |
| Wavelength | nm | 1310/1550 |
| Insertion Loss | dB | ≤0.30 |
| Return Loss | dB | ≥ 60 |
| Connection type | SC/APC | |
| Ferrule | Ceramic | |
| Connection cycles | 500 | |
| Cable Jacket Color | Black | |
| Cable Outer Diameter | mm |
（5.2x2.0）*±0.2mm （3.0x2.0）*±0.2mm (without messenger) |
| Fiber Mode | Single mode: G657A2 | |
| Cable Jacket Material | LSZH | |
| Cable weight | kg/km | 20±3 |
| Printing contents | Customizable | |
| Length | m |
100 or Customizable (Tolerance: ±0.5m) |
| Connector type | Input: Accord H Optic SC/APC | |
| Output: Without Connector | ||
|
Traction (axial between cable and connector) |
N | 100 |
| Waterproof Grade | IP68 | |
| Operating Temperature | ℃ | -20°C ~ +65℃ |
| Storage Temperature | ℃ | -20°C ~ +65℃ |
| Optical Fiber | Type | G-657 A2. |
| No. Fibers | 1 | |
| Color | Blue | |
| Outer Sheath | Dimension |
（5.2x2.0）*±0.2mm （3.0x2.0）*±0.2mm (without messenger) |
| Material | LSZH | |
| Color | Black | |
| Steel Strength Member | Materia | Steel Wire |
| Diameter | 0.45mm | |
| Steel Self Strength Member | Materia | Steel Wire |
| Diameter | 1.2 mm | |
| Weight | 20±3 Kg/Km | |
| Tersile (N) |
Long term: 300N Short term: 600 N |
|
| Crush | 1000N/10cm | |
| Min. Bending Radius |
15xD (Static); 30xD (Dynamic) |
|
| Temperature Range | -20°C to +65°C | |
All characteristics of the cable fiber (fiber of finished cable) shall be, at least, in accordance with the ITU-T Recommendation G.657A2 and shall be as follows.
| Parameter | Specification | |
| Attenuation coefficient |
@ 1310 nm @ 1383 nm @ 1550 nm @ 1625 nm |
≤ 0.36 dB/km ≤ 0.36 dB/km ≤ 0.22 dB/km ≤ 0.24 dB/km |
| Attenuation (After cable) | @1310nm | ≤0.40dB/km |
| @1550nm | ≤0.30dB/km | |
| Uniformity of attenuation at 1310nm | ≤0.05dB | |
| Uniformity of attenuation at 1550nm | ≤0.05dB | |
| Cable cut-off wavelength (λcc) | ≤ 1260 nm | |
| Zero-dispersion wavelength | 1300 ~ 1324 nm | |
| Zero-dispersion slope | ≤ 0.092 ps/(nm^2.km) | |
| Absolute value of dispersion at 1288nm~1339nm | ≤3.5ps/(nm·km) | |
| Absolute value of dispersion at 1271nm~1360nm | ≤5.3ps/(nm·km) | |
| Dispersion at 1550nm | ≤18ps/(nm·km) | |
| Dispersion at 1625nm | ≤23ps/(nm·km) | |
| Mode field diameter (MFD) at 1310nm | 8.60±0.4μm | |
| Mode field diameter (MFD) at 1550nm | 9.4-10.4μm | |
| Polarization mode dispersion (PMD) Fiber | ≤0.125ps/km1/2 | |
| Polarization mode dispersion (PMD) Cable | ≤0.200ps/km1/2 | |
| PMD coefficient | M | 20 cables |
| Q | 0.01% | |
| PMDQ | ≤0.20ps/km1/2 | |
| Geometrical characteristics | ||
| Cladding diameter | 125±0.8μm | |
| Cladding non-circularity | ≤1.0% | |
| Core/cladding concentricity error | ≤0.8μm | |
| Fiber diameter with coating (uncolored) | 245±10μm | |
| Fiber diameter with coating (colored) | 250±10μm | |
| Cladding/coating concentricity error | ≤12.0μm | |
| Tension test | 100kpsi or 0.69GPa | |
| Removal of the coating (N) | 1.0～9.0 | |
| Mechanical characteristics | ||
| Macrobend loss at 1550nm | R=15mm,10 turns | ≤0.03dB |
| R=10mm,1turn | ≤0.10dB | |
| R=7.5mm,1turn | ≤0.5dB | |
| Macrobend loss at 1625nm | R=15mm,10 turns | ≤0.10dB |
| R=10mm,1turn | ≤0.20dB | |
| R=7.5mm,1turn | ≤1.0dB | |
Carton Size：600*320*265mm ，Transparent sealing tape "I" font sealing box.
Wooden plate size：1200 *1000mm.
Stacking requirements: one layer of six boxes, stacking six layers.
Top 4 right Angle protection, and then use "#" font packing belt tightly.
